304 316L Stainless Steel Capillary Tube; Seamless Tube; Laser Slot Micro-Hole Processing

Name: 304 316L Stainless Steel Capillary Tube Seamless Tube Laser Slot MicroHole Processing
Brand: yue lin sen
Price: 0.5 USD

Cheap 304 316L Stainless Steel Capillary Tube; Seamless Tube; Laser Slot Micro-Hole Processing wholesale

Brand Name : yue lin sen

Model Number : Y62

Certification : ISO9001 ISO13485

Place of Origin : Dongguan, Guangdong

MOQ : 100 pcs

Price : 0.5-20

Payment Terms : T/T

Supply Ability : 500000pcs5

Delivery Time : 5-8 work days

Packaging Details : vacuum packaging; cardboard box

Hs Code : 7301200000

Surface Treatment : Polished

Model No : 201 202 304 316 316L 2205

Origin : Dongguan, Guangdong

Edge : Beveled, Plain, Threaded

Seamless Pipe : 1.0mm - 40mm or custom

Type : Stainless steel capillary tube

Industry : medical industry

Specification : 260*200*120

Technique : Cold Drawn

Usage : Fluid and Gas Transport

Transport Package : Plastic Bag; Cardboard Box

Length Tolerance : +/-10mm

Standard : ASTM,DIN,AISI,JIS,GB

Color : Silver, Gold, Rose Red, Blue, Bronze etc

Contact Now

304 316L Stainless Steel Capillary Tube; Seamless Tube; Laser Slot Micro-Hole Processing

Product Description

We specialize in the precision manufacturing of 304 and 316L Stainless Steel Capillary and Seamless Tubes, enhanced with advanced Laser Slotting and Micro-Hole Machining. Our products are engineered for applications demanding ultra-precise fluid conveyance, gas flow, instrumentation, and miniaturized components.

The use of 304/316L stainless steel provides excellent corrosion resistance, high strength, and durability. The laser machining process offers a burr-free, heat-controlled, and highly accurate method for creating complex micro-features on these small-diameter tubes without inducing significant mechanical stress, making them ideal for critical use in medical, semiconductor, and analytical industries.

Technical Parameters

The following table outlines the key specifications for our tubing and laser machining services.

Parameter Category	Specifications & Capabilities
Material	304 Stainless Steel (AISI 304) & 316L Stainless Steel (AISI 316L)
Tubing Type	Capillary Tubes, Seamless Tubes
Standard Outer Diameter (OD)	0.5 mm to 10 mm (0.020" to 0.394")
Standard Wall Thickness	0.1 mm to 1.5 mm (0.004" to 0.059")
Standard Length	Up to 6000 mm (236"), custom lengths available
Tolerance	OD: ±0.01mm (±0.0004") WT: ±10% Cut Length: ±0.1mm
Laser Machining Capabilities	Micro-Hole Drilling: Diameter from 0.05 mm (50µm) Slotting: Minimum width from 0.03 mm (30µm) Positional Accuracy: ± 0.01 mm
Surface Finish	Bright Annealed, Pickled, Electropolished (upon request)
Available Certifications	Material Certificates (3.1 EN 10204), RoHS Compliance

Product Applications

These precision tubes are designed for highly specialized industries where accuracy, reliability, and miniaturization are critical.

Industry	Specific Applications
Medical & Surgical Devices	Hypodermic needle tubing, catheter shafts, endoscopic instrument channels, fluid delivery tubes, guide wires, surgical staplers.
Semiconductor Manufacturing	Gas distribution lines, chemical delivery lines, wafer processing wand tubes, sensor housings.
Chromatography & Analytical Instruments	HPLC & GC capillary columns, sample transfer lines, probe needles, fluidic connectors.
Precision Mechanics & Sensors	Sheaths for temperature sensors, pressure sensor capillaries, pneumatic control lines, fiber optic protection tubes.
Aerospace & Defense	Hydraulic lines for miniature systems, fuel injection lines, cooling channels for avionics.
